Paper cups, paper bags, carton pre-printing, food packaging, tobacco and alcohol outer packaging, drug packaging, daily necessities, non-woven fabrics, plastic films, industrial products, and other flexible packaging materials.
Paper cups, paper bags, carton pre-printing, food packaging, tobacco and alcohol outer packaging, drug packaging, daily necessities, non-woven fabrics, plastic films, industrial products, and other flexible packaging materials.
|
Model |
KSJH-2S-B-850mm |
KSJH-2S-B-1050mm |
KSJH-2S-B-1350mm |
KSJH-2S-B-1650mm |
|
Raw material width |
800mm |
1000mm |
1300mm |
1600mm |
|
Maximum printing width |
770mm |
970mm |
1270mm |
1570mm |
|
Printing color |
2-12 color（Customers can choose according to requirements） |
|||
|
Printing length range |
360mm-960mm |
|||
|
Raw material diameter |
Ф1500mm |
|||
|
Maximum mechanical speed |
50-230m/min |
|||
|
Maximum printing speed |
50-220m/min |
|||
|
Color registration accuracy |
± 0.12mm |
|||
|
Chromatic mode |
1. Vertical: computer automatic color registration 2. Horizontal: Electric |
|||
|
Voltage |
3P380V |
|||
|
size |
depends on the model |
|||
|
weight |
depends on the model |
|||
|
Other optional functions |
1. Fully automatic non-stop unwind&rewind 2. Sleeve plate roller mesh roller device 3. Pressure regulation: servo motor control 4. Anti color device 5. UV and bronzing device 6. Slitting, breaking and film covering device |
|||
Main features:
1. The whole machine is controlled by PC and servo motor control system, and equipped with remote service device, which is convenient to solve problems quickly;
2. The color registration adopts automatic computer automatic color registration and HD color still picture monitoring, which is convenient for the observation of printing quality;
3. It is applicable to the duplex type of paper unwinding without core, and it is applicable to the automatic unwinding position of + 6 inches; Full automatic roll changing without shutdown, material receiving speed is 260m / min.
1.Function: multi-color continuous fine printing, at the same time to achieve reverse gluing
2.Features: accurate color matching, stable operation, model customization
3.Application: mask packaging, pharmaceutical paper packaging, food paper packaging
Main features:
1. The whole machine is controlled by PC and servo motor control system; And equipped with remote service device to facilitate and quickly solve problems;
2. The color registration adopts automatic computer automatic color registration and HD color still picture monitoring, which is convenient for the observation of printing quality;
3. Unwinding adopts shaftless hydraulic automatic feeding, which is suitable for 3 + 6 inch paper core;
