carton pre-printing, Paper cup, paper bag, food packaging, tobacco and alcohol packaging, pharmaceutical packaging, daily
necessities, and other flexible packaging materials
carton pre-printing, Paper cup, paper bag, food packaging, tobacco and alcohol packaging, pharmaceutical packaging, daily
necessities, and other flexible packaging materials
1. Drive mode: servo system drive
2. Color printing method: automatic computer overprinting device
3. Detection system: color printing effect monitoring system
4. Advance and retreat system:
plate roller and anilo roller are electrically controlled, which can achieve fast advance and retreat
5. Inking mode: fullyenclosed scraper inking system
6. Tension control: multi-section tension control, floating roller detection, automatic control
7.Applicable ink: water-based ink, solvent ink and UV ink
8. Drying device: extended drying system is adopted for color group drying
9. Dry heat source: electricity, steam, thermal oil, natural gas, etc
10. Discharge correction: adopt high precision deviation correction device
11. Feeding control: automatic control with pneumatic brake
12. Rewind control: controlled by frequency
conversion motor
|
Model |
KSJP-S-B-1300 |
KSJP-S-B-1600 |
KSJP-S-B-1900 |
KSJP-S-B-2500 |
|
|
Max Material Width |
1300mm |
1600mm |
1900mm |
2500mm |
|
|
Max Printing width |
1270mm |
1570mm |
1870mm |
2470mm |
|
|
Printing length |
380-1300mm |
380-1300mm |
380-1300mm |
380-1300mm |
|
|
Printing color |
4-10 color |
||||
|
Mechanical speed |
50-300m/min |
||||
|
Printing speed |
50-280m/min |
||||
|
Printing unit Composition |
Ceramic anilox roller, Chamber doctor blade, Ink pump, Printing cylinder, Pressure roller |
||||
|
Voltage |
3p 380v 50hz |
||||
|
Weight |
Depends on models |
||||
|
Dimension |
Depends on models |
||||
|
Optional devices |
1.Laminating device 2.Reverse printing 3.Corona treatment 4.Automatic non-stop unwind&rewind 5.Online device |
||||
Main features:
1. The whole machine is controlled by PC and servo motor control system, and equipped with remote service device, which is convenient to solve problems quickly;
2. The color registration adopts automatic computer automatic color registration and HD color still picture monitoring, which is convenient for the observation of printing quality;
3. It is applicable to the duplex type of paper unwinding without core, and it is applicable to the automatic unwinding position of + 6 inches; Full automatic roll changing without shutdown, material receiving speed is 260m / min.
1.Function: multi-color continuous fine printing, at the same time to achieve reverse gluing
2.Features: accurate color matching, stable operation, model customization
3.Application: mask packaging, pharmaceutical paper packaging, food paper packaging
Main features:
1. The whole machine is controlled by PC and servo motor control system; And equipped with remote service device to facilitate and quickly solve problems;
2. The color registration adopts automatic computer automatic color registration and HD color still picture monitoring, which is convenient for the observation of printing quality;
3. Unwinding adopts shaftless hydraulic automatic feeding, which is suitable for 3 + 6 inch paper core;
